stwquattro´s 1984 Audi 4000 S turbo quattro - 10VT KG

Author Message
 Post subject: stwquattro´s 1984 Audi 4000 S turbo quattro - 10VT KG
PostPosted: Tue Dec 04, 2007 5:09 am
Offline
Redline?

Joined: Mon Dec 03, 2007 9:16 am
Posts: 120
Hello to all.

I want to introduce myself and my car. I´m Sebastian, 28, from Lichtenstein/Saxony in Germany. Currently i study automotive engineering in the 7th semester and i work at http://www.thielert.com" onclick="window.open(this.href);return false; in the flight test department.

My car is an Audi 4000 S quattro... "My Little White Beauty" ...it has left the assembly line at the 5th january in 1984. He spent the first years of his life in Bremerton/WA until 1986...(as written in the service certificate).It was originally JT-equipped, but i changed the engine in 2006 because of a coolant leakage into the cylinder...because of the low compression ratio of...8:1 i didn´t want to put more work than necessary into this engine. i looked for a NG engine because of the better comp ratio and the possibility of getting a better tax...in germany called Euro 2...

i got one of the first NG in a good condition.it has a KV camshaft originally built in and in combination with the three-pipe-exhaust-manifold, the car is a better cruiser.... no race car ;)

the 17inch ZENDER rims are now...the 5th or 6th sort of rims i drove on my 4Kq. for these rims i had to set the suspension new....in front there are bonrath bearings (adjustable camber), koni golf mk 1 shock absorbers and fichtel&sachs 35mm springs (for front axle) mounted.in the back there are original bearings,kayaba gaspressure shock absorbers and G&M 60mm springs (for front axle) mounted.

the dimensions of the Zender rims: 7,5x17inch ET35 with 205/40R17 Nankang ... at the rear axle there are additionally distances mounted...15mm on every side.

my special interest are exhaust systems...i always built them on my own...urquattro mufflers etc...BUT...this year my friends built a new exhaust system for me...76mm...3inch...the engine won´t need this diameter, but i love the deep sound...just gorgeous!!!

so the whole exhaust system has a diameter of 76mm / 3inch...even the catalyst (an original metal catalyst from a BMW E30 - fits perfect like the original Audi catalysts...same dimensions!!!).
The exhaust needs to be polished...completely polished because of rust protection...i´ll do it the next weeks.

AND its a good base for installing a turbo-charged engine soon.

So i hope my english is not too bad and you guys understand me as good as possible :)

some pics of the car (the pics with the flat hubs at the rims are the newest ones):


the front muffler...
the rear muffler...
the whole system...i´ll change the pipe to the tailpipes as soon as possible into 3inch...we haven´t had time for long welding sessions :)

some nice documents...


Last edited by stwquattro on Wed Feb 19, 2014 4:20 am, edited 1 time in total.

Top
 Profile
Reply with quote
 Post subject:
PostPosted: Tue Dec 04, 2007 7:22 am
Offline
I sprinkle rubber on my Cherios
User avatar

Joined: Mon Jan 02, 2006 5:55 am
Posts: 288
Location: sweden
Nice :D so you're friend mad those mufflers for you, i like the rear one. i got some inspiration no to build one rear muffler just like yours

_________________
ABT C5 437WHPpLord Of The Rings
Audi SportQuattro : 9.996 @ 142.738 MPH 630WHp
kostic.nu

Sponsors BSR KRB EAAB 034


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Tue Dec 04, 2007 7:39 am
Offline
Redline?

Joined: Mon Dec 03, 2007 9:16 am
Posts: 120
if i got my pics back, i´ll send u more pics from the muffler.

which kind of car should get the muffler??

if u want, he could built the muffler for u.

regards, bastian[/img]


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Tue Dec 04, 2007 10:43 am
Offline
kickin' tires'n lightin fires
User avatar

Joined: Fri Jun 16, 2006 8:02 pm
Posts: 575
Location: Littleton Colorado
Great car! .... and your English is just fine, you write better then most of us Americans.

_________________
Ryan
----
'86 Vanagon Syncro AWP 1.8T
'86 4kq DD
'07 Touareg V6 For Sale


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Tue Dec 04, 2007 12:09 pm
Offline
I sprinkle rubber on my Cherios
User avatar

Joined: Mon Jan 02, 2006 5:55 am
Posts: 288
Location: sweden
stwquattro wrote:
if i got my pics back, i´ll send u more pics from the muffler.

which kind of car should get the muffler??

if u want, he could built the muffler for u.

regards, bastian


Yes i more pics would be nice, i am going to build it for my "Sport Quattro project"

_________________
ABT C5 437WHPpLord Of The Rings
Audi SportQuattro : 9.996 @ 142.738 MPH 630WHp
kostic.nu

Sponsors BSR KRB EAAB 034


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Tue Dec 04, 2007 4:22 pm
Offline
mach 2 with my hair on fire
User avatar

Joined: Wed Dec 24, 2003 10:15 pm
Posts: 2351
Location: Holland, MI Dutch Mafia!
Nice car.

Steve

_________________
Stephen Ankney
2000 Audi TTq
1986 Audi 5ktq w/MSEFI, TO4E/K26, parts
1986 Audi 5ktq w/MSEFI, Stebro, Torsen, etc.
1999 A6q Stock.
------------------------------------------------------
https://www.motorgeek.com/phpBB2/viewtopic.php?t=7813


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Tue Dec 04, 2007 5:07 pm
Offline
I'm compensating for something with this
User avatar

Joined: Sat Oct 04, 2003 8:28 am
Posts: 17178
Location: West Coast- silverton,OR & Sacramento,CA
i love your car Sebastian.... glad to see you make it around here :)

_________________
Ð3Я3К....
86' 4kq~OG Alpine Weiss *Comatose*
83' URQ~project secrecy
85' 4kq 20vt~The Sniper 8) *alive*
01' A6 4.2~6spd conversion, Gallardo 19's*sold*
83' 4ks 2dr*DD protege'*
85' diamond 4kq*DD*


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Tue Dec 04, 2007 6:04 pm
Offline
Stuck in first
User avatar

Joined: Fri Oct 17, 2003 3:45 pm
Posts: 22
Location: Grand Rapids, MI
Man, I'm digging those Zender wheels. Very old-school. Look great on your 4kq!

_________________
90 90q20v - daily driver/snowmobile
81 VW Pickup 2.0 8v - former tint-mobile turned auto-cross toy
86 Porsche 944t - boost toy


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Wed Dec 05, 2007 12:12 pm
Offline
mach 2 with my hair on fire
User avatar

Joined: Fri Mar 26, 2004 3:02 pm
Posts: 2945
Location: Milton, Canada
Beautiful car. Is there any other US 4kq in Europe that you know of?

What's with the hump in the trunk (driver side)?
Whas that a modification to get a full size spare in?
Just wondering.

_________________
Martin Pajak
www.quattro.ca
82 Ur-q - SQ project, long term
83 80 q - Euro 2-door!!
85 Ur-q - Euro with 3B
93 90 quattro - S2 Limo copy
93 80q Avant - 2.5TDI, 6-speed in the works
04 A4q avant 1.8T USP 6-speed
04 A4q avant 3.0 USP 6-speed


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Wed Dec 05, 2007 12:38 pm
Offline
Redline?

Joined: Tue Dec 04, 2007 11:20 am
Posts: 173
Location: Waterloo, IA
Very nice! The white and black look great - beautiful car!

_________________
http://www.lichty.com


- 1991 Audi Coupe Quattro 3B swap in progress!!
- 1991 GTI full VR6 swap
- 2005.5 Audi A4 2.0T Quattro


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Wed Dec 05, 2007 1:15 pm
Offline
Redline?

Joined: Mon Dec 03, 2007 9:16 am
Posts: 120
@ rallyquattro

i hope i understood u right...yes...its for the spare wheel...but its just a small one...15inch and...about 4,5inch wide.

don´t your 4kq´s have this hump??

there are a few 4k in europe, which i know...also a 4kq...a 86 i believe...but absolutely no '84 4kq...

in my opinion, my '84 4Kq is the only one...in good drivable conditions...but i would be lucky if i´m wrong. ;)


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Wed Dec 05, 2007 1:48 pm
Offline
mach 2 with my hair on fire
User avatar

Joined: Fri Mar 26, 2004 3:02 pm
Posts: 2945
Location: Milton, Canada
Yes, all have bunps, but yours looks way different than any I've seen before.. in fact it's in the way of the exhaust.
Here is an example.. obviously this one is the facelift car so it has the "trench" behind the bumper, but look at the spare whell bump.
http://www.quattro.ca/19874kq/DSC05394.JPG

_________________
Martin Pajak
www.quattro.ca
82 Ur-q - SQ project, long term
83 80 q - Euro 2-door!!
85 Ur-q - Euro with 3B
93 90 quattro - S2 Limo copy
93 80q Avant - 2.5TDI, 6-speed in the works
04 A4q avant 1.8T USP 6-speed
04 A4q avant 3.0 USP 6-speed


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Wed Dec 05, 2007 1:51 pm
Offline
Redline?

Joined: Mon Dec 03, 2007 9:16 am
Posts: 120
its a '84 quattro...so we might ask other '84 owners, if they have the hump in the trunk like my 4kq.


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Wed Dec 05, 2007 5:20 pm
Offline
mach 2 with my hair on fire
User avatar

Joined: Fri Mar 26, 2004 3:02 pm
Posts: 2945
Location: Milton, Canada
stwquattro wrote:
its a '84 quattro...so we might ask other '84 owners, if they have the hump in the trunk like my 4kq.


I have exact same car as yours:


I looked at it again and I think it's just the way it looks in the pic.
So I think it's just an illusion.

_________________
Martin Pajak
www.quattro.ca
82 Ur-q - SQ project, long term
83 80 q - Euro 2-door!!
85 Ur-q - Euro with 3B
93 90 quattro - S2 Limo copy
93 80q Avant - 2.5TDI, 6-speed in the works
04 A4q avant 1.8T USP 6-speed
04 A4q avant 3.0 USP 6-speed


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Thu Dec 06, 2007 12:05 am
Offline
Redline?

Joined: Mon Dec 03, 2007 9:16 am
Posts: 120
thats possible...


the tinte windows look very nice at the red one :-)


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Thu Dec 06, 2007 2:10 am
Offline
I boggle like it's my bidniss

Joined: Sun Nov 30, 2003 6:50 am
Posts: 8119
Location: I see the world different thanks to my steering wheel
They say wheels can make or break a project.This is definately one of my most favourite 4000S's!

_________________
Issam N. Abed
iABEDIndustries.com


Top
 Profile
Reply with quote
 Post subject: 1984
PostPosted: Thu Dec 06, 2007 2:37 am
Offline
kickin' tires'n lightin fires
User avatar

Joined: Mon Dec 18, 2006 3:03 am
Posts: 920
Location: Up the street from Javad's place
Like fine wine, the older they get the better the body... I am on my second 1984 4000kq, both were Tornado Red, my second 84 car is now done a full KH swap, 034 just called me today they finished up what I started, I'll post pictures when I get the car cleaned up some more. I have always liked the early cars, for some reason they have a different feel, anyone??


Attachments:
Audi 01 winter 98.jpg
Audi 01 winter 98.jpg [ 412.54 KiB | Viewed 6380 times ]
Top
 Profile
Reply with quote
 Post subject:
PostPosted: Fri Dec 07, 2007 3:04 am
Offline
Redline?

Joined: Mon Dec 03, 2007 9:16 am
Posts: 120
@ ralleyquattro

are these tinted windows the original ones or did u tint them again with gluing foil or something like that?the look really dark...quite nice.


bastian


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Fri Dec 07, 2007 5:55 am
Offline
mach 2 with my hair on fire
User avatar

Joined: Fri Mar 26, 2004 3:02 pm
Posts: 2945
Location: Milton, Canada
Aftermarket tint done by previous owner.
Yes, it is very dark.
I am actually thinking of taking it off.. don't really like tinted windows.

_________________
Martin Pajak
www.quattro.ca
82 Ur-q - SQ project, long term
83 80 q - Euro 2-door!!
85 Ur-q - Euro with 3B
93 90 quattro - S2 Limo copy
93 80q Avant - 2.5TDI, 6-speed in the works
04 A4q avant 1.8T USP 6-speed
04 A4q avant 3.0 USP 6-speed


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Fri Dec 07, 2007 6:53 am
Offline
Redline?

Joined: Mon Dec 03, 2007 9:16 am
Posts: 120
@ rallleyquattro

so tell me the price...i´l take them. :)

seriously!

bastian


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Fri Dec 07, 2007 7:40 am
Offline
mach 2 with my hair on fire
User avatar

Joined: Fri Mar 26, 2004 3:02 pm
Posts: 2945
Location: Milton, Canada
I don't think I can take it off in one pice.. if I am lucky and I can take it off nicely I'll ship it out for cost of shipping.. sound good?

_________________
Martin Pajak
www.quattro.ca
82 Ur-q - SQ project, long term
83 80 q - Euro 2-door!!
85 Ur-q - Euro with 3B
93 90 quattro - S2 Limo copy
93 80q Avant - 2.5TDI, 6-speed in the works
04 A4q avant 1.8T USP 6-speed
04 A4q avant 3.0 USP 6-speed


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Fri Dec 07, 2007 9:01 am
Offline
I post, therefore I am

Joined: Fri Jun 18, 2004 8:32 pm
Posts: 7423
Location: Fort Wayne, Indiana
ralleyquattro wrote:
Aftermarket tint done by previous owner.
Yes, it is very dark.
I am actually thinking of taking it off.. don't really like tinted windows.


Im with ya on that one. Ive never owned a car with tinted windows, dont really have the desire to do it.

Personal preference, fa sho :)

_________________
1986 4kq CE
1991 200 20v wagon


Top
 Profile Facebook
Reply with quote
 Post subject:
PostPosted: Fri Dec 07, 2007 9:07 am
Offline
Redline?

Joined: Mon Dec 03, 2007 9:16 am
Posts: 120
of course!!!

are all windows tinted??


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Fri Dec 07, 2007 9:56 am
Offline
I'm compensating for something with this
User avatar

Joined: Sat Oct 04, 2003 8:28 am
Posts: 17178
Location: West Coast- silverton,OR & Sacramento,CA
is tinting really so expensive over there Sebastian? it costs me about $250 to have all 7 rear windows on a 4kq tinted here... i would think shipping would cost way more than that to germany! plus the fact that if you find a good tinter, it should come with a decent warranty. all my windows come with a lifetime warranty on the tint.

i like tinted windows...

_________________
Ð3Я3К....
86' 4kq~OG Alpine Weiss *Comatose*
83' URQ~project secrecy
85' 4kq 20vt~The Sniper 8) *alive*
01' A6 4.2~6spd conversion, Gallardo 19's*sold*
83' 4ks 2dr*DD protege'*
85' diamond 4kq*DD*


Top
 Profile
Reply with quote
 Post subject:
PostPosted: Fri Dec 07, 2007 10:05 am
Offline
I post, therefore I am
User avatar

Joined: Wed Jan 07, 2004 2:26 pm
Posts: 11635
Location: Findlay, Ohio
The V8 and CQ will probably get tinted this spring...CQ darker, as it doesn't have AC.

_________________
http://coupe.gofergusons.org
'13 Q7 TDI
'07 Q7 3.6
'90 CQ 32v
'90 CQ 0v


Top
 Profile
Reply with quote
Display posts from previous:  Sort by
Post new topic Reply to topic  [ 52 posts ] Go to page 1, 2, 3  Next
Search this topic:
motorgeek.com :: Board index :: Motorgeek Madness :: Projects

Jump to:



Information

Users browsing this forum: No registered users and 3 guests



You cannot post new topics in this forum
You cannot reply to topics in this forum
You cannot edit your posts in this forum
You cannot delete your posts in this forum
You cannot post attachments in this forum
  |  It is currently Fri Aug 07, 2020 10:41 pm
Share |
